Jumho Electric RWU-LCD Remote Display Panel Module | Part No. 556675-02

Jumho Electric RWU-LCD Automation Remote Indicator Display

Centralize your machinery oversight and improve operational visibility with the Jumho Electric RWU-LCD Remote Display Panel. Engineered to excel inside challenging marine environments like vessel bridges and engine control rooms, this dedicated display unit loops directly into your main PLC data bus, allowing operators to cross-examine alarms and change operational profiles remotely.

The front layout includes dual independent numeric LED status tracking windows alongside a complete cursor movement keypad. Dedicated tactile quick-action buttons are mapped at the bottom right for instantaneous audio management and circuit continuity confirmation.

The back panel is populated with dual rows of high-integrity green pluggable terminal block strips featuring clearly etched wire assignments for system safety loops:

• Power Terminals: Low-voltage DC inputs (V+, V-).

• System Diagnostic Rails: Dedicated hardware failure contactors (FAIL) and an integrated audible alarm driver link (SIREN).

• Dual Data Network Links: Isolated interface ports supporting master/slave configurations over differential communication runs (COM1+, COM1-, SHIELD and COM2+, COM2-, SHIELD).

Technical Specifications:

• Brand: JUMHO Electric

• Model Configuration: RWU-LCD (RWULCD)

• Part Tracking Number: 556675-02

• System Serial Sequence: 2200-100113

• Operator Interface: Backlit LCD Center Panel, 8x Function Hotkeys, 5-Way Directional Pad

• Network Architecture: Dual Serial Network Interfaces (COM1 & COM2 with Dedicated Shielding)

• Local Controls: Manual increase/decrease backlight dimmer toggles (+ / -)

• Mounting Design: Flush panel-mount frame (includes 4x threaded stainless steel tie-down mounting anchors shown in 3.jpeg)

• Target Automation Fields: Marine Engine Monitoring Systems (EMS), Vessel Control Consoles, Industrial Distributed I/O Racks, Auxiliary Alarm Status Displays

Key Features:

• Dual-Port Redundant Networking: Outfitted with dual COM ports to maintain uninterrupted signal feeds, switching data channels if a network line drops.

• Technician-Focused Diagnostics: Features built-in hardware testing controls (Ack/Test) to quickly check local LEDs, screens, and internal buzzers without disrupting the broader machinery bus.

• High-Contrast Dimming Range: Equipped with manual front-facing dimmer keys, letting operators drop backlight intensity to protect night vision on vessel bridges during evening operations.

• Complete Installation Kit: Supplied with original high-density protective foam seating and all four structural threaded mounting hooks, minimizing time spent fabricating brackets on the factory floor or shipyard dock.
