IFM ELECTRONIC POWER SUPPLY 1206 AS Interface (AS-i) Switching Mode Power Supply
₨ 0
The ifm electronic AC1206 (AC 1206) is an AS-Interface (AS-i) switching mode power supply designed for industrial automation and DIN rail mounting.
Technical Specifications
- Input Voltage: Selectable 110 VAC / 230 VAC (Input range: 88…132 V / 184…264 V AC)
- Input Frequency: 47–63 Hz (50/60 Hz nominal)
- Output Voltage: 29.5…31.6 V DC
- Output Current: 2.8 A (Max. output current)
- Output Power: 88 W
- Housing Design: DIN rail mounting (IP20 protection rating)
- Integrated Data Decoupling: Yes
- Protections: Short-circuit protection, overload protection, integrated internal fuse (2.5 A, non-accessible)
- Operating Temperature: -10 °C to 60 °C
IFM ELECTRONIC POWER SUPPLY 1206 AS Interface (AS-i) Switching Mode Power Supply
