The WAGO 750-610 is an industrial 24 VDC internal power supply module engineered for the WAGO I/O System 750. It passes electrical potential down the local bus to downstream I/O modules, features an integrated 5×20 mm fuse holder for system protection, and provides native diagnostic feedback via a status LED to monitor fuse failure.

• Input & Output Voltage: 24 VDC nominal (-25% to +30%)
• Current Capacity: Up to 10 A max. through the internal power jumper contacts (note: individual segment limit may vary based on configuration)
• Wiring Technology: Patented CAGE CLAMP® spring pressure system for vibration-proof, tool-free connections
• Physical Profile: 12 mm width, 100 mm height, 69.8 mm depth; designed for standard DIN-35 rail mounting
• Safety & Approvals: ATEX, IECEx, and UL listed for Class I, Division 2 hazardous locations.
