PANASONIC FP0R-E32 EXPANSION UNIT MODEL NO. AFP0RE32T
₨ 0
The Panasonic AFP0RE32T is a 32-point digital input and transistor output expansion module designed for the FP0R Series Programmable Controllers.
Key Specifications
- Module Type: Digital Input and Transistor (NPN/open-collector) Output Expansion Unit
- Input Points: 16 digital inputs (24 V DC rated voltage, 5.1 kΩ impedance, photocoupler insulated)
- Output Points: 16 transistor outputs (5–24 V DC load voltage, max 0.3 A per point)
- Power Supply: 24 V DC (range 21.6–26.4 V DC)
- Mounting Style: DIN Rail
- Operating Temperature: 0°C to +55°C
- Width: Ultra-compact 25 mm profile designed to attach to the right side of FP0R base control units
PANASONIC FP0R-E32 EXPANSION UNIT MODEL NO. AFP0RE32T
